G6RN-1A12VDC

Quantity	excl. VAT	VAT incl.
1 - 1	4.43£	5.32£
2 - 2	4.21£	5.05£
3 - 4	4.07£	4.88£
5 - 9	3.09£	3.71£
10 - 15	2.88£	3.46£

Quantity	U.P
1 - 1	4.43£	5.32£
2 - 2	4.21£	5.05£
3 - 4	4.07£	4.88£
5 - 9	3.09£	3.71£
10 - 15	2.88£	3.46£

Delivery in 2-3 days, with postal tracking!

Quantity in stock : 15

Set of 1

G6RN-1A12VDC. ROHS: Yes. Max current: 8A. Contact type: SPDT. Voltage in Volts: 250V AC. Assembly/installation: PCB. Pitch of terminals: 5.1mm. Operating temperature: -40...85°C. External dimensions: 28.5x10x15mm. Configuring Contacts: SPST-NO. Relay type: electromagnetic. Coil rated voltage: 12V DC. Switching voltage: max 250VAC. max 30VDC. Coil resistance: 655 Ohms. Switching time: 15ms. Time to switch back: 5ms. Coil Power Consumption: 220mW. Manufacturer Series: G6RN. Coil current: 18.3mA. Max current/contact (VDC): 5A / 30VDC. Max current/contact (VAC): 8A / 250VAC. Original product from manufacturer Omron. Quantity in stock updated on 29/07/2025, 20:25.
